User Adjustable Digital Panel Meter -
Loop Powered 4-20mA DC Panel Meters
Window Mount
Bezel Mount
Snap-In Bezel Mount
1/8 NEMA4 DIN
3 1/2 Digit Panel Meter Features:
- Shallow depth < 1 inch.
- 3 1/2 digit (1999 counts)
- Loop drop only 2.2V DC (Optional 1.5V DC)
- Fully Integrated Process Meter - No Add-On or Plug-In Boards.
- Snap-In Bezel panel meters - no mounting hardware required.
- Switch selectable SPANS for accurate & stable adjustment in engineering units.
- 25 turn SPAN & OFFSET adjustments for accurate calibration
- Switch selectable decimal points.
- Space saver case requires 60% less panel space comparing with 1/8 DIN case.
- Screw terminal connector.
Process Output Loop Current from a transducer or transmitter (4 to 20mA DC) can be displayed in engineering units. A 4 to 20mA DC output can be adjusted to display up to 0 to 1999 counts.
Application:
Switch selectable SPANS with accurate high resolution 25 turn potentiometers for scaling in engineering units. Offers stable and easy calibration verses other meters without multiple spans.
Switch Selectable OFFSETS - Positive or negative Offset selectable. Accurate adjustment with 25 turn high resolution potentiometer. Range -20% to +60% of span.
Example:
4 to 20mA DC output display -200C to 1500C.
4 to 20mA DC output display 0 to 1450 FEET.
Input Ranges:
DC Voltage: 4 to 20mA DC
EXAMPLES of User Adjustable Loop Powered Input, 4-20mA, Panel Meters (For details, click Ordering Guide):
SI640ADZ, SI740ADZ, SI742ADZ-A, SI746ADZ-A, SI940ADZ, SID40ADZ, SID46ADZ-C
